H84xx
INSTALLATION GUIDE
SETUP
Set Up the Power Meter
1. Press -----> until you see SETUP.
2. Press SETUP. Enter your password (Default password is 00000).
3. Press + to change a digit, <----- to select the next digit.
4. Press OK.
Set Up CTs
1. Press CT. ----->
2. Enter the PRIM CT (primary CT) number (1 to 32767, using the + and <-----
buttons).
3. Press OK.
Set Up PTs
1. Press PT. The default is NO PT. Single Phase System types (10, 11, 12) do not allow
PTs.
2. Press +
3. Select the SCALE value: x1, x10, x100, NO PT (for direct connect).
4. Press OK.
5. Enter the PRIM (primary) value.
6. Press OK.
7. Enter the SEC. (secondary) value.
8. Press OK.
Set Up the System Frequency
1. Press -----> until HZ is visible.
2. Press HZ.
3. Press + to select the frequency: 50 Hz or 60 Hz (default is 60Hz).
4. Press OK.
