H84xx INSTALLATION GUIDE
H8436-FDS H8437-EDS
H8400
REG.
R/W NV Format Units
Scale
Factor/
Mult.
Range Description
Per Phase
• • 273/274 R Float kW Real Power, Phase A
• • 275/276 R Float kW Real Power, Phase B
• • 277/278 R Float kW Real Power, Phase C
• • 279/280 R Float Ratio 0.0-1.0 Power Factor, Phase A
• • 281/282 R Float Ratio 0.0-1.0 Power Factor, Phase B
• • 283/284 R Float Ratio 0.0-1.0 Power Factor, Phase C
• • 285/286 R Float Volt Voltage, Phase A-B
• • 287/288 R Float Volt Voltage, Phase B-C
• • 289/290 R Float Volt Voltage, Phase A-C
• • 291/292 R Float Volt Voltage, Phase A-N
• • 293/294 R Float Volt Voltage, Phase B-N
• • 295/296 R Float Volt Voltage, Phase C-N
• • 297/298 R Float Amp Current, Instantaneous, Phase A
• • 299/300 R Float Amp Current, Instantaneous, Phase B
• • 301/302 R Float Amp Current, Instantaneous, Phase C
--- EDS ---
• 303/304 R Float Amp Current, Instantaneous, Neutral
• 305/306 R Float Hz 45.0-65.0 Frequency (derived from Phase A)
• 307/308 R NV Float kW Total Real Power Minimum
• 309/310 R NV Float kW Total Real Power Maximum
• 311/312 R NV Float kVAh Apparent Energy Consumption
• 313/314 R NV Float kVARh Reactive Energy Consumption
Per Phase Power
• 315/316 R Float kVA Apparent Power, Phase A
• 317/318 R Float kVA Apparent Power, Phase B
• 319/320 R Float kVA Apparent Power, Phase C
• 321/322 R Float kVAR Reactive Power, Phase A
• 323/324 R Float kVAR Reactive Power, Phase B
• 325/326 R Float kVAR Reactive Power, Phase C
Demand
• 327/328 R Float kW Total Real Power Present Demand
• 329/330 R Float kVA Total Apparent Power Present Demand
• 331/332 R Float kVAR Total Reactive Power Present Demand
• 333/334 R NV Float kW Total Real Power Max Demand
• 335/336 R NV Float kVA Total Apparent Power Max Demand
• 337/338 R NV Float kVAR Total Reactive Power Max Demand
Usage Time
• 339/340 R NV Float Hours >= 0.0 Usage Hours
This combination
timer counts the
total time for
which the absolute
current on at least
one phase is >0.1
Amp.
• 341/342 R NV Float Minutes 0.0-59.0 Usage Minutes
• 343/344 R NV Float Hours >= 0.0 Total Hours
This timer counts the
total time since the
usage timer was
reset. • 345/346 R NV Float Minutes 0.0-59.0 Total Minutes
• 347/348 R NV Float % 0.0-100.0 Percent Usage
Percent Usage =
Usage Time / Total
Time.
