H84xx INSTALLATION GUIDE
MODBUS POINT MAP
H8436-FDS H8437-EDS
H8400
REG.
R/W NV Format Units
Scale
Factor/
Mult.
Range Description
Integer Statistics
3-Phase Summary
--- BDS ---
• • 001 R NV
ULong
kWh E 0-0xFFFF Real Energy Consumption (LSW)
• • 002 R NV kWh E 0-0xFFFF Real Energy Consumption (MSW)
• • 003 R UInt kW W 0-32767 Total Instantaneous Real Power (3 Phase Total)
--- FDS ---
• • 004 R UInt kVA W 0-32767 Total Instantaneous Apparent Power (3 Phase Total)
• • 005 R UInt kVAR W 0-32767 Total Instantaneous Reactive Power (3 Phase Total)
• • 006 R UInt Ratio 0.0001 0-10000 Total Power Factor (Total kW / Total kVA)
• • 007 R UInt Volt V 0-32767 Voltage, L-L, Average of 3 Phases
• • 008 R UInt Volt V 0-32767 Voltage, L-N, Average of 3 Phases
• • 009 R UInt Amp I 0-32767 Current, Average of 3 Phases
Per Phase
• • 010 R UInt kW W 0-32767 Real Power, Phase A
• • 011 R UInt kW W 0-32767 Real Power, Phase B
• • 012 R UInt kW W 0-32767 Real Power, Phase C
• • 013 R UInt Ratio 0.0001 0-10000 Power Factor, Phase A
• • 014 R UInt Ratio 0.0001 0-10000 Power Factor, Phase B
• • 015 R UInt Ratio 0.0001 0-10000 Power Factor, Phase C
• • 016 R UInt Volt V 0-32767 Voltage, Phase A-B
• • 017 R UInt Volt V 0-32767 Voltage, Phase B-C
• • 018 R UInt Volt V 0-32767 Voltage, Phase A-C
• • 019 R UInt Volt V 0-32767 Voltage, Phase A-N
• • 020 R UInt Volt V 0-32767 Voltage, Phase B-N
• • 021 R UInt Volt V 0-32767 Voltage, Phase C-N
• • 022 R UInt Amp I 0-32767 Current, Instantaneous, Phase A
• • 023 R UInt Amp I 0-32767 Current, Instantaneous, Phase B
• • 024 R UInt Amp I 0-32767 Current, Instantaneous, Phase C
--- EDS ---
• 025 R UInt Amp I 0-32767 Current, Instantaneous, Neutral
• 026 R UInt Hz 0.01 4500-6500 Frequency (derived from Phase A)
• 027 R NV UInt kW W 0-32767 Total Real, Power Minimum
• 028 R NV UInt kW W 0-32767 Total Real, Power Maximum
Accumulated Energy
• 029 R NV
ULong
KVAh E 0-0xFFFF Apparent Energy Consumption (LSW)
• 030 R NV KVAh E 0-0xFFFF Apparent Energy Consumption (MSW)
• 031 R NV
ULong
KVARh E 0-0xFFFF Reactive Energy Consumption (LSW)
• 032 R NV KVARh E 0-0xFFFF Reactive Energy Consumption (MSW)
Per Phase Power
• 033 R UInt kVA W 0-32767 Apparent Power, Phase A
• 034 R UInt kVA W 0-32767 Apparent Power, Phase B
• 035 R UInt kVA W 0-32767 Apparent Power, Phase C
• 036 R UInt kVAR W 0-32767 Reactive Power, Phase A
• 037 R UInt kVAR W 0-32767 Reactive Power, Phase B
• 038 R UInt kVAR W 0-32767 Reactive Power, Phase C
