29
Gas sampling and gas conditioning technology 2-1.1.7.6-ME
N O T E !
For cleaning the injection nozzle, you need not necessarily pull the nozzle
out of the T-piece. The nozzle can be cleaned together with the complete T-
piece in an ultrasonic bath.
If you blow through the nozzle, this must be done from the jet pipe side.
17 SPARE PARTS LIST
The wear, tear and spare part requirements depend on the specific operating conditions.
The following table shows an extract of the recommended spare parts for the diluiton units DIL-1 and
DIL-1/H :
Recommended spare parts
Part No. Description
20 S 4300 Complete set critical orifice incl. 2x o-rings. Material: glass # Please specify dilution ra-
tio along with order. #
93 S 4000 Injection nozzle incl. o-ring (crosspiece)
93 S 4006 Dilution crosspiece empty, without any inserts, material: SS316
93 S 4016 Bypass T-piece empty, without any inserts, material: SS316
93 S 4020 Crosspiece complete. # Please specify dilution ration along with order #
93 S 4025 Bypass T-piece complete
90 S 4035 Suction tube for DIL 6x1mm with integrated filter sieve incl. Swagelok® nuts, silver-
plate cutting ring for dilution crosspiece, material SS316
93 S 0010 Spare thermostate 0-180°C
93 S 0015 Spare heating cartridge HLP, 230V 800W
93 S 0017 Spare heating cartridge HLP, 115V 800W
93 S 0018 Heat conductivity paste for insertion of heating cartridge
93 S 4015 Eductor incl. O-ring for bypass-T-piece
18 APPENDIX
Further documentation of our products can be seen in our internet catalogue:
www.mc-techgroup.com
