Gas sampling and gas conditioning technology 2-1.1.7.6-ME
The connections for the supply and sample lines are as follows:
Connection Dimension
Sample In (undiluted) Tube 6 x 1mm
Testgas in Tube 6 x 1mm
Dilution gas In Tube 6 x 1mm
Low pressure manometer Tube 6 x 1mm
Sample gas Out (diluted) Tube 8 x 1mm
Option I:
Bypass gas In
Tube 6 x 1mm
Bypass gas Out (diluted) Tube 6 x 1mm
Option II:
Sample gas Out (undiluted)
Tube 6 x 1mm
13.2 CONNECTION OF SAMPLE GAS AND HEATED SAMPLE LINES
All connections for the sample gas or heated sample lines are tube connectors out of stainl. steel suit-
able for connection of stainl. steel tubes or hose pipes with dimension 6x1mm. Only the outlet of the
diluted sample gas is dimensioned for stainl. steel tube or flexible tube of 8x1mm.
N O T E !
When connecting hose pipes to stainl. Steel fittings, a supporting sleeve
must always be used.
The connection must be checked for tightness.
The connection to the non heated versions DIL-1 is made directly to the respective fittings (see figure
1).
The connection of the heated sample lines to the heated versions DIL-1/H is shown in figure 2.

Remove the protective cover

Open the fastening clamp

Mount the hose pipe or tube to the respective fittings

Shut the fastening clamp again

Install the protective cover again.
