12.8.3 Device mode
This menu point selects via the Direction keys
⇑⇓
whether
the analyser works as a single-channel version or as a
multi-channel (max. 4 channels) version.
The choice is confirmed by the Enter key. If single-channel
version is selected the Select key leads to the beginning of
the menu.
Operating the Select key with the multi-channel version
leads to the next menu point.
12.8.4 Select channel
The channels 1 to 4 can be activated or deactivated by the
Direction keys
⇑⇓
.
The Select key leads to the next channel.
After the 4 th channel, the Select key leads to the next menu
point.
12.8.5 Arrangement of the mA-outputs
At this menu point max. 4 channels can be reserved via the
Direction keys
⇑⇓
with mA-signals for the following
functions:
• O
2
- value channel 1 to 4,
• process pressure channel 1 to 4, and
• cell temperature.
The jump into the submenu happens via the Enter key.
The respective function is selected via the Direction keys
⇑⇓
, and confirmed by the Enter key.
Select leads to the next menu point.
12.8.6 Set active valve
Maximum 8 solenoid valves are pre-reserved with an
identification No.
The Select key leads to the beginning of the menu.
device mode
single-chan. mod
↑↑
Enter ⇑⇑⇑⇑⇑ ⇓⇓⇓⇓⇓
Select
select channel
channel 1: on/off
↑↑
Select ⇑⇑⇑⇑⇑ ⇓⇓⇓⇓⇓
Select
select DAC
current output 1
↑↑
Enter ⇑⇑⇑⇑⇑ ⇓⇓⇓⇓⇓
Enter
Select
set active valve
(1-8): 65071000
↑↑
Enter ⇑⇑⇑⇑⇑ ⇓⇓⇓⇓⇓
Enter
Select
