relay config.
relay 1
A selection is done by the Direction keys
⇑⇓
and confirmed
by the Enter key.
The Select key leads to the next menu point.
12.4.6 Status error mA
Using a permanent current output signal, status errors can
be identified. The output signal is selected via the Direction
keys
⇑⇓
and confirmed by the Enter key.
The following output signals are available:
•
no output signal
•
0
mA
•
2
mA
•
20,5 mA
•
21
mA
•
22
mA
•
22,5 mA
•
23
mA
•
24
mA
The Select key leads to the next menu point.
12.4.7 Set date/time
The Enter key enables the entry of the date/time values:
first month, day and year, then hour and minute.
The first changeable position is underlined and can be
changed operating the Direction keys
⇑⇓
.
A jump to the next position happens via the Select key.
The entry has to be confirmed by the Enter key, and
operating once more the Select key leads to the next menu
point.
12.4.8 Relay configuration
This menu point determines the function of maximum four
relays, R1 to R4 (see 7.5 technical data). A selection of the
relays is done by the Direction keys
⇑⇓ .
The Enter key opens the Entry and the Direction keys
⇑⇓
select the desired function:
• allocation of the measuring ranges 1 to 4
• measuring span error
• concentration alarm (1 to 4)
• calibration
• flow alarm
• external alarm (see 12.4.9).
The Enter key confirms the selection.
The Select key leads to the next menu point.
This menu point selects whether the relay functions as:
0
normally open contact
1
normally closed contact
The entry starts with the Enter key. The first changeable
position is underlined and can be changed operating the
Direction keys
⇑⇓
. A jump to the next position happens via
the Select key.
The entry has to be confirmed by the Enter key, and the
Select key leads to the next menu point.
Enter
⇑⇑⇑⇑⇑
⇓⇓⇓⇓⇓
Select
Enter
⇑⇑⇑⇑⇑
⇓⇓⇓⇓⇓
set date/time
MM-DD-YY hh:mm
status error mA
no, 0mA, 2mA, 20,5mA, ...
⇑⇑⇑⇑⇑
⇓⇓⇓⇓⇓
Enter
Enter
⇑⇑⇑⇑⇑
⇓⇓⇓⇓⇓
Select
Select
relay config.
R1: span1...4,conc. alarm1...4
↑↑
↑↑
relay nc = 1
1:0 2:0 3:0 4:0
Select
Enter
Select
Enter
Select
Enter
⇑⇑⇑⇑⇑
⇓⇓⇓⇓⇓
