12.4
Parameterising level 1
12.4.1 Language
The following languages are selectable by the Direction
keys
⇑⇓
:
• English,
• German,
• French.
Enter confirms the choice.
The Select key leads to the next menu point.
12.4.2 Select range
After the entry of the code for level 1 the display opens to
the select range menu. Four variable ranges and the auto-
range are available. The functions can be selected by the
Direction keys
⇑⇓
. With the autorange always the favour-
able range is used.
In combination with the autorange function, unused measuring
ranges are requested to be set to 0 (see 12.4.3).
The Select key leads to the next menu point.
12.4.3 Set range
The desired ranges 1 to 4 or the autorange are selected by
the Direction keys
⇑⇓ .
The display is opened for changes
by the Enter key. The first changeable position is
underlined and can be changed operating the Direction
keys
⇑⇓
. A jump to the next position happens via the
Select key. The entry of the complete measuring range has
to be confirmed by the Enter key.
The Select key leads to the next menu point.
12.4.4 Set autorange hysteresis
This adjustment is important using the autorange function.
The %-value is related to the smallest span of the relevant
switching ranges and determines the interval switching into
the next lower range (see 14.1).
The entry starts with the Enter key. The first changeable
position is underlined and can be changed operating the
Direction keys
⇑⇓
. A jump to the next position happens via
the Select key.
The entry has to be confirmed by the Enter key, and the
Select key leads to the next menu point.
12.4.5 Current output
Two adjustments are possible:
1. fixed output signal and
2. output signal with range of tolerance showing the
underflow respectively exceeding of the signal range.
The following ranges are preseted:
• 0 - 20mA
•
0 - 20mA + 0,45mA
• 2 - 20mA
•
2 - 20mA
±
0,45mA
• 4 - 20mA
•
4 - 20mA
±
0,45mA
set range 1
xx%O
2
- xxx,x%O
2
Enter
⇑⇑⇑⇑⇑
⇓⇓⇓⇓⇓
current output
0-20mA, 2-20mA, ...
Select
Select
Enter
Select
Enter
⇑⇑⇑⇑⇑
⇓⇓⇓⇓⇓
⇑⇑⇑⇑⇑
⇓⇓⇓⇓⇓
Select
Enter
↑↑
↑↑
language
English
↑↑
set hyst. autor.
xx.xx%
Enter
⇑⇑⇑⇑⇑
⇓⇓⇓⇓⇓
Select
Enter
Enter
⇑⇑⇑⇑⇑
⇓⇓⇓⇓⇓
select range 1
r1(...4), autorange
