16
Gas sampling and gas conditioning technology 3-4.20-ME
N O T E !
When fixing the connectors in the PVDF heat exchanger hold up with a
wrench at the pane of the bolt head!
The connection for the gas inlet (see above) is made to the heat exchanger
of the pre-cooling stage 
3 (fig. 2). This is marked accordingly with an arrow.
The outlet for gas to be measured, DN 4/6, is located as standard on the
universal unit EC-F located on the underside of the cooler casing (fig. 2).
When using the automatic condensate removal EC-FD, the connection for
the outlet for gas to be measured will be made to the corresponding
connector on the front panel of the universal unit (fig. 2).
In the standard configuration, the tubes for removal of condensate are connected directly to the heat
exchangers.
These protrude with the 12mm tube connectors above the base plate of the cooler casing (fig. 2).
Condensate removal is done according to the type of operation with:

Universal unit EC-FD with peristaltic pumps for automatic condensate removal;

Automatic float condensate trap and remover AD-... only for over-pressure operation;

Condensate collector container that has to be drained manually.
13.2 ELECTRICAL CONNECTIONS
W A R N I N G !
When connecting the equipment, please ensure that the supply
voltage is identical with the information provided on the model
type plate.
N O T E !
Attention must be paid to the requirements of IEC 364 (DIN VDE
0100) when setting high-power electrical units with nominal
voltages of up to 1000 V, together with the associated standards
and stipulations.
Check the details on the type plate to ensure that the equipment is
connected up to the correct mains voltage.
The main circuit must be equipped with a fuse of 10A
T
(over
current protection); for electrical details see technical data.
