10
Gas sampling and gas conditioning technology 3-4.20-ME
8 TECHNICAL DATA
Cooler series EC
®
Version EC-30 Version EC-30/FD
Part No. 02K6000 (a)** 02K6010 (a)**
With integrated universal unit: EC-F to force the ventilation EC-FD ventilation and
condensate removal
Gas connection tube connector DN 4/6 i./o. d. mm
Condensate connections 3x tube connector GL25-12 mm 1x tube connector DN 4/6 i./o. d.
mm
Material of sample contacting parts Duran glass, PTFE, PVDF Duran glass, PTFE, PVDF,
Novoprene
Single stream, gas flow rate 90 Nl/hr-250 Nl/hr*
Gas pressure max. 3 bar abs. max. 2 bar abs.
Ambient temperature +5 to +45 °C
Storage temperature -20 to +60°C
Sample outlet dew point -30 °C
Sample inlet temperature max. 180 °C*
Sample inlet dew point max. 80 °C*
Cooling capacity at 25 °C ambient max. 860 kJ/hr*
Main power connection / Power
consumption 230V 50Hz 380VA or **Part No. ...-a = 115V 60 Hz 380VA
Start up time < 60 min.
Stagnant space approx.160 ml
Δ P at 250 Nl/hr flow rate 5 mbar
Electrical connection 2,5 mm
2
terminals, 2x PG13,5 cable glands
Status alarm 2 changeover contacts, potential free contact rating 250V, 3A,
500VA, 50W
Case protection / Electrical equipment
standard IP20 EN 60529 / EN 61010
Method of mounting / Case colour 19" rack or wall / case colour RAL 9003
Dimension / Weight 84 TE x 8 HE x 360 mm / 37 kg 84 TE x 10 HE x 360 mm / 42 kg
**
Maximum values in technical datas must be rated in consideration of total cooling capacity at 25 °C ambient temperature and an outlet
dew point of 5 °C.
9 DESCRIPTION
The patented M&C gas cooler EC-30(/FD) is a two stage combination of compressor and Peltier
cooler with status alarm and automatic defrosting of the dual deep freezer unit for 100% sample
availability. The pre-cooler  of the gas cooler EC- is
fitted with a “Jet-Stream“ heat exchanger EC-G
which is cooled by a compressor cooling unit with electronic control at a constant temperature of +1°C.
Optimum cooling of sample gases and pre-elemination of a larger part of the condensate from the gas
is reliably achieved. No external pre-draining is normally needed. The deep freezer  and  is cooled
with t
wo modified “Jet-Stream“ heat exchangers EC-30 fitted between two automatic cooling units for a
minimum temperature of -30 °C. The special design of the Jet-Stream heat exchanger guarantees
optimum dew point reduction to a low, stable value and secures condensate separation. The gas
outlets of the heat exchangers are connected to a 3/2 way solenoid valve. An electronic control system
EC-30 switches the solenoid valve for simultaneous changeover and automatic defrosting of the heat
exchangers EC-30. In order to guarantee the necessary and minimum operation of the gas cooler EC-
30, we provide this unit with an accessory module EC-F containing two fans for forced air ventilation
and cooling of the compressor unit. Alternative we deliver the cooler with the module EC-FD
containing additionally three peristaltic pumps SR-25.1 for automatic removal of condensate.
