Area Description
1. Recorder
Channel pane This pane provides the functions to start or stop the recorder
channels.
See section "Recorder Channel Pane" on page 2 for a description
of the user interface elements.
2. Clip Creation
pane This pane provides the functions to create a clip.
See section "Clip Creation Pane" on page 4 for a description of
the user interface elements.
1.2.2. Recorder Channel Pane
Overview of the Recorder Channel Pane
The Recorder Channel pane contains the main areas highlighted on the following
screenshot and shortly described in the table below.
2 1. Recorder Panel
