INSIO Version 1.0 – User Manual
EVS Broadcast Equipment – October 2009
Issue 1.0.D
51
H
OW TO
R
ECORD A
S
TREAM
To record stream(s), proceed as follows:
1. Select the scene you want to work on from the list in the Scene field or with
the
buttons.
2. You can select which cameras will be active when recording a take.
From the list of cameras,
• deselect the cameras you do not want to record the take by clearing the
check box on the corresponding line(s)
• select the cameras you want to record the take by selecting the check box
on the corresponding line(s)
OR
• press the Check All button to select all the cameras.
3. Press the Start/In button to start recording the stream(s).
The stream is not saved on the server and is directly sent to the transfer
destination defined in Setup > User > Predefined Configurations >
Format, Name & Destination.
4. Press the Stop/Out button to stop the recording of the stream(s).
