3Com 2924-PWR - Manual (Page 85)

Defining Access Control Lists 85
Removing ACL
Binding
The ACL Binding Remove Page allows the network administrator to
remove user-defined ACLs from a selected interface.
Monitor users have no access to this page.
To remove ACL Binding:
1 Click Device > ACL > ACL Binding > Remove. The ACL Binding Remove
Page opens:
Figure 37 ACL Binding Remove Page
The ACL Binding Remove Page contains the following fields:
■ Checkbox (unnamed) — Marks the ACL for removal.
■ Interface — Displays the port interface to which the ACL is bound.
■
ACL Name — Displays the name of ACL to be removed from the
selected port.
2 For each ACL to be removed, check the box to the left of the row in the
table. To remove all ACLs, the topmost box may be checked.
3 Click . The selected ACLs are removed, and the device is
updated.
