34 C HAPTER 2: U SING THE 3C OM W EB I NTERFACE
Figure 8 Web Interface Components
The following table lists the user interface components with their
corresponding numbers:
This section provides the following additional information:
■
Device Representation — Provides an explanation of the user
interface buttons, including both management buttons and task
icons.
■
Using the 3Com Web Interface Management Buttons — Provides
instructions for adding, modifying, and deleting configuration
parameters.
Table 6: Interface Components
Vi e w D e s c r i p t i o n
1 Tree View Tree View provides easy navigation through the configurable
device features. The main branches expand to display the
sub-features.
2 Tab View The Tab Area enables navigation through the different device
features. Click the tabs to view all the components under a spe-
cific feature.
3 Web Inter-
face Informa-
tion
Provides access to online help, and contains information about
the Web Interface.
