103
■
10 — Indicates the port is currently operating at 10 Mbps.
■
100 — Indicates the port is currently operating at 100 Mbps.
■
1000 — Indicates the port is currently operating at 1000 Mbps.
■
Auto — Use to automatically configure the port.
■
No Change — Retains the current port speed.
■
Duplex — Specifies the port duplex mode. This field is configurable
only when auto negotiation is disabled, and the port speed is set to
10M or 100M. The possible field values are:
■
Auto — Use to automatically configure the port.
■
Full — The interface supports transmission between the device and
its link partner in both directions simultaneously.
■
Half — The interface supports transmission between the device
and the client in only one direction at a time.
■
No Change — Retains the current port duplex mode.
■ Flow Control — Specifies the flow control status on the port.
Operates when the port is in full duplex mode. The possible field
values are:
■
Enable — Enables flow control on the port.
■
Disable — Disables flow control on the port.
■
No Change — Retains the current flow control status on port.
■ Reactivate — Reactivates a port if the port has been shutdown
through a device security option . The possible field values are:
■
Reactivate — Reactivates a port.
■
No Change — Retains the current port status.
■ Select Ports — Selects the ports to be configured.
2 Define the fields.
3 Click . The ports are configured, and the device is updated.
