Prestige 660H/HW Series User’s Guide
Chapter 4 Wizard Setup for Media Bandwidth Management 66
C
H A P T E R
4
Wizard Setup for Media
Bandwidth Management
This chapter shows you how to configure basic bandwidth management using the wizard
screens.
4.1 Introduction to Media Bandwidth Management
The web configurator’s Media Bandwidth Magnt. screens under Wizard Setup allows you
to specify bandwidth classes based on an application (or service). You can allocate specific
amounts of bandwidth capacity (bandwidth budgets) to different bandwidth classes.
The Prestige applies bandwidth management to traffic that it forwards out through an
interface. The Prestige does not control the bandwidth of traffic that comes into an interface.
Bandwidth management applies to all traffic flowing out of the Prestige through the interface,
regardless of the traffic's source.
Traffic redirect or IP alias may cause LAN-to-LAN traffic to pass through the Prestige and be
managed by bandwidth management.
Refer to Chapter 18 on page 194 for more information and advanced configuration.
4.1.1 Predefined Media Bandwidth Management Services
The following is a description of the services that you can select and to which you can apply
media bandwidth management using the Wizard Setup screens.
Table 10 Media Bandwidth Mgnt. Wizard Setup: Services
SERVICE DESCRIPTION
Xbox Live This is Microsoft’s online gaming service that lets you play multiplayer Xbox games
on the Internet via broadband technology. Xbox Live uses port 3074.
VoIP (SIP) Sending voice signals over the Internet is called Voice over IP or VoIP. Session
Initiated Protocol (SIP) is an internationally recognized standard for implementing
VoIP. SIP is an application-layer control (signaling) protocol that handles the
setting up, altering and tearing down of voice and multimedia sessions over the
Internet.
SIP is transported primarily over UDP but can also be transported over TCP, using
the default port number 5060.
