Prestige 660H/HW Series User’s Guide
215 Chapter 19 Maintenance
19.4 Any IP Table Screen
Click Maintenance, Any IP. The Any IP table shows current read-only information
(including the IP address and the MAC address) of all network devices that use the Any IP
feature to communicate with the Prestige. Refer to
Section 6.5 on page 76 for more
information.
Figure 114 Any IP Table
The following table describes the labels in this screen.
Table 66 Any IP Table
LABEL DESCRIPTION
# This field displays the index number.
IP Address This field displays the IP address of the network device.
MAC Address This field displays the MAC (Media Access Control) address of the computer with the
displayed IP address.
Every Ethernet device has a unique MAC address. The MAC address is assigned at
the factory and consists of six pairs of hexadecimal characters, for example,
00:A0:C5:00:00:02.
Refresh Click Refresh to update this screen.
19.5 Wireless Screen
The read-only screen displays information about the Prestige’s wireless LAN.
19.5.1 Association List
This screen displays the MAC address(es) of the wireless stations that are currently logged in
to the network. Click Wireless LAN and then Association List to open the screen shown next.
