Prestige 660H/HW Series User’s Guide
Chapter 26 Remote Node Configuration 254
26.3 Remote Node Network Layer Options
For the TCP/IP parameters, perform the following steps to edit Menu 11.3 – Remote Node
Network Layer Options as shown next.
1 In menu 11.1, make sure IP is among the protocols in the Route field.
2 Move the cursor to the Edit IP/Bridge field, press [SPACE BAR] to select Yes, then
press [ENTER] to display Menu 11.3 – Remote Node Network Layer Options.
Figure 140 Menu 11.3 Remote Node Network Layer Options
Menu 11.3 - Remote Node Network Layer Options
IP Options: Bridge Options:
IP Address Assignment = Static Ethernet Addr Timeout(min)= N/A
Rem IP Addr = 0.0.0.0
Rem Subnet Mask= 0.0.0.0
My WAN Addr= 0.0.0.0
NAT= SUA Only
Address Mapping Set= N/A
Metric= 2
Private= No
RIP Direction= None
Version= RIP-1
Multicast= None
IP Policies=
Enter here to CONFIRM or ESC to CANCEL:
The next table explains fields in Menu 11.3 – Remote Node Network Layer Options.
Table 85 Menu 11.3 Remote Node Network Layer Options
FIELD DESCRIPTION
IP Address
Assignment
Press [SPACE BAR] and then [ENTER] to select Dynamic if the remote node is using
a dynamically assigned IP address or Static if it is using a static (fixed) IP address.
You will only be able to configure this in the ISP node (also the one you configure in
menu 4), all other nodes are set to Static.
Rem IP Addr This is the IP address you entered in the previous menu.
Rem Subnet
Mask
Type the subnet mask assigned to the remote node.
My WAN Addr Some implementations, especially UNIX derivatives, require separate IP network
numbers for the WAN and LAN links and each end to have a unique address within
the WAN network number. In that case, type the IP address assigned to the WAN port
of your Prestige.
NOTE: Refers to local Prestige address, not the remote router address.
NAT Press [SPACE BAR] and then [ENTER] to select Full Feature if you have multiple
public WAN IP addresses for your Prestige.
Select SUA Only if you have just one public WAN IP address for your Prestige. The
SMT uses Address Mapping Set 255 (see Figure 158 on page 271 ).
Select None to disable NAT.
