Prestige 660H/HW Series User’s Guide
Chapter 18 Media Bandwidth Management Advanced Setup 208
Figure 110 Media Bandwidth Management: Monitor
The following table describes the labels in this screen.
Table 62 Media Bandwidth Management: Monitor
LABEL DESCRIPTION
Interface Select an interface from the drop-down list box to view the bandwidth usage of
its bandwidth classes.
Class Name This field displays the name of the class.
Budget (kbps) This field displays the amount of bandwidth allocated to the class.
Current Usage (kbps) This field displays the amount of bandwidth that each class is using.
Back Click Back to go to the main Media Bandwidth Management screen.
Refresh Click Refresh to update the page.
