Prestige 660H/HW Series User’s Guide
217 Chapter 19 Maintenance
Figure 116 Diagnostic: General
The following table describes the fields in this screen.
Table 68 Diagnostic: General
LABEL DESCRIPTION
TCP/IP
Address
Type the IP address of a computer that you want to ping in order to test a connection.
Ping Click this button to ping the IP address that you entered.
Reset System Click this button to reboot the Prestige. A warning dialog box is then displayed asking
you if you're sure you want to reboot the system. Click OK to proceed.
Back Click this button to go back to the main Diagnostic screen.
19.6.2 Diagnostic DSL Line Screen
Click Diagnostic and then DSL Line to open the screen shown next.
