Prestige 660H/HW Series User’s Guide
357 Chapter 40 Internal SPTGEN
40.2.1 Internal SPTGEN File Modification - Important Points to
Remember
Each parameter you enter must be preceded by one “=”sign and one space.
Some parameters are dependent on others. For example, if you disable the Configured field in
menu 1 (see
Figure 237 on page 356 ), then you disable every field in this menu.
If you enter a parameter that is invalid in the Input column, the Prestige will not save the
configuration and the command line will display the Field Identification Number.
Figure
238 on page 357 , shown next, is an example of what the Prestige displays if you enter a value
other than “0” or “1” in the Input column of Field Identification Number 1000000 (refer
to
Figure 237 on page 356 ).
Figure 238 Invalid Parameter Entered: Command Line Example
field value is not legal error:-1
ROM-t is not saved, error Line ID:10000000
reboot to get the original configuration
Bootbase Version: V2.02 | 2/22/2001 13:33:11
RAM: Size = 8192 Kbytes
FLASH: Intel 8M *2
The Prestige will display the following if you enter parameter(s) that are valid.
Figure 239 Valid Parameter Entered: Command Line Example
Please wait for the system to write SPT text file(ROM-t)...
Bootbase Version: V2.02 | 2/22/2001 13:33:11
RAM: Size = 8192 Kbytes
FLASH: Intel 8M *2
40.3 Internal SPTGEN FTP Download Example
1 Launch your FTP application.
2 Enter " bin ". The command “ bin ” sets the transfer mode to binary.
3 Get " rom-t " file. The command “ get ” transfers files from the Prestige to your computer.
The name “ rom-t ” is the configuration filename on the Prestige.
4 Edit the " rom-t " file using a text editor (do not use a word processor). You must leave
this FTP screen to edit.
