Prestige 660H/HW Series User’s Guide
257 Chapter 26 Remote Node Configuration
Figure 143 Menu 11.5 Remote Node Filter (PPPoA or PPPoE Encapsulation)
Menu 11.5 - Remote Node Filter
Input Filter Sets:
protocol filters=
device filters=
Output Filter Sets:
protocol filters=
device filters=
Call Filter Sets:
protocol filters=
device filters=
Enter here to CONFIRM or ESC to CANCEL:
26.5 Editing ATM Layer Options
Follow the steps shown next to edit Menu 11.6 – Remote Node ATM Layer Options.
In menu 11.1, move the cursor to the Edit ATM Options field and then press [SPACE BAR]
to select Yes. Press [ENTER] to display Menu 11.6 – Remote Node ATM Layer Options.
There are two versions of menu 11.6 for the Prestige, depending on whether you chose VC-
based/LLC-based multiplexing and PPP encapsulation in menu 11.1.
26.5.1 VC-based Multiplexing (non-PPP Encapsulation)
For VC-based multiplexing, by prior agreement, a protocol is assigned a specific virtual
circuit, for example, VC1 will carry IP. Separate VPI and VCI numbers must be specified for
each protocol.
Figure 144 Menu 11.6 for VC-based Multiplexing
Menu 11.6 - Remote Node ATM Layer Options
VPI/VCI (VC-Multiplexing)
VC Options for IP:
VPI #= 8
VCI #= 35
ATM QoS Type= UBR
Peak Cell Rate (PCR)= 0
Sustain Cell Rate (SCR)= 0
Maximum Burst Size (MBS)= 0 VC Options for Bridge:
VPI #= 1
VCI #= 36
ATM QoS Type= N/A
Peak Cell Rate (PCR)= N/A
Sustain Cell Rate (SCR)= N/A
Maximum Burst Size (MBR)= N/A
Enter here to CONFIRM or ESC to CANCEL:
26.5.2 LLC-based Multiplexing or PPP Encapsulation
For LLC-based multiplexing or PPP encapsulation, one VC carries multiple protocols with
protocol identifying information being contained in each packet header.
