Chapter 7 Basic Setting
GS-4012F/4024 User’s Guide
85
7.7 Port Setup
Use this screen to configure Switch port settings.Click Basic Setting and then Port Setup in
the navigation panel to display the configuration screen.
Apply Click Apply to save your changes to the Switch’s run-time memory. The Switch loses
these changes if it is turned off or loses power, so use the Save link on the top
navigation panel to save your changes to the non-volatile memory when you are done
configuring.
Cancel Click Cancel to reset the fields to your previous configuration.
IP Interface
Use these fields to create or edit IP routing domains on the Switch.
IP Address Enter the IP address of your Switch in dotted decimal notation for example
192.168.1.1. This is the IP address of the Switch in an IP routing domain.
IP Subnet
Mask Enter the IP subnet mask of an IP routing domain in dotted decimal notation. For
example, 255.255.255.0.
VID Enter the VLAN identification number to which an IP routing domain belongs.
Add Click Add to save your changes to the Switch’s run-time memory. The Switch loses
these changes if it is turned off or loses power, so use the Save link on the top
navigation panel to save your changes to the non-volatile memory when you are done
configuring.
Cancel Click Cancel to reset the fields to your previous configuration.
Index This field displays the index number of an entry.
IP Address This field displays IP address of the Switch in the IP domain.
Subnet Mask This field displays the subnet mask of the Switch in the IP domain.
VID This field displays the VLAN identification number of the IP domain on the Switch.
Delete Click Delete to remove the selected entry from the summary table.
Note: Deleting all IP subnets locks you out from the Switch.
Cancel Click Cancel to clear the Delete check boxes.
Table 11 Basic Setting > IP Setup (continued)
LABEL DESCRIPTION
