Chapter 27 RIP
GS-4012F/4024 User’s Guide
228
Figure 119 RIP
The following table describes the labels in this screen.
Table 82 RIP
LABEL
DESCRIPTION
Active
Select this check box to enable RIP on the Switch.
Index
This field displays the index number of an IP interface.
Network
This field displays the IP interface configured on the Switch.
Refer to the section on IP Setup for more information on configuring IP domains.
Direction
Select the RIP direction from the drop-down list box. Choices are Outgoing, Incoming,
Both and None.
Version
Select the RIP version from the drop-down list box. Choices are RIP-1, RIP-2B and RIP-
2M.
Apply
Click Apply to save your changes to the Switch’s run-time memory. The Switch loses
these changes if it is turned off or loses power, so use the Save link on the top navigation
panel to save your changes to the non-volatile memory when you are done configuring.
Cancel
Click Cancel to begin configuring the fields again.
