Page 72
Chapter 6 System Status and Port Statistics
GS-4012F/4024 User’s Guide
72
6.2.1 Status: Port Details
Click a number in the Port column in the Status screen to display individual port statistics.
Use this screen to check status and detailed performance data about an individual port on the
Switch.
Link
This field displays the speed (either 10M for 10Mbps, 100M for 100Mbps or 1000M
for 1000Mbps) and the duplex (F for full duplex or H for half). It also shows the cable
type (Copper or Fiber) for the combo ports.
State
If STP (Spanning Tree Protocol) is enabled, this field displays the STP state of the
port (see
for more information).
If STP is disabled, this field displays FORWARDING if the link is up, otherwise, it
displays STOP.
LACP
This fields displays whether LACP (Link Aggregation Control Protocol) has been
enabled on the port.
TxPkts
This field shows the number of transmitted frames on this port.
RxPkts
This field shows the number of received frames on this port.
Errors
This field shows the number of received errors on this port.
Tx KB/s
This field shows the number of kilobytes per second transmitted on this port.
Rx KB/s
This field shows the number of kilobytes per second received on this port.
Up Time
This field shows the total amount of time in hours, minutes and seconds the port has
been up.
Clear Counter
Enter a port number and then click Clear Counter to erase the recorded statistical
information for that port, or select Any to clear statistics for all ports.
Table 6 Status (continued)
LABEL
DESCRIPTION
