Chapter 4 Tutorial
ZyXEL NWA-3160 Series User’s Guide
72
4.4.5 Configure the SERVER_2 Network
Next, you will configure the SERVER_2 network that allows Bob to access secure server 2
and the Internet.
To do this, repeat the procedure in
Section 4.4.4 on page 69 , substituting the following
information.
4.4.6 Checking your Settings and Testing the Configuration
Use the following sections to ensure that your wireless networks are set up correctly.
4.4.6.1 Checking Settings
Take the following steps to check that the ZyXEL Device is using the correct SSIDs, MAC
filters and layer-2 isolation profiles.
1 Click WIRELESS > Wireless. Check that the Operating Mode is MBSSID and that
the correct SSID profiles are selected and activated, as shown in the following figure.
Table 10 Tutorial: SERVER_2 Network Information
SSID Screen
Index 4
Profile Name SERVER_2
SSID Edit (SERVER_2) Screen
L2 Isolation L2Isolation04
MAC Filtering macfilter04
Layer-2 Isolation (L2Isolation04) Screen
Profile Name L-2-ISO_SERVER-2
Set 1 MAC Address: 77:66:55:44:33:22
Description: NET_ROUTER
Set 2 MAC Address: 99:88:77:66:55:44
Description: SERVER_2
Set 3 MAC Address: 66:55:44:33:22:11
Description: GATEWAY
MAC Filter (macfilter04) Edit Screen
Profile Name MacFilter_SERVER_2
Set 1 MAC Address: 22:33:44:55:66:77
Description: Bob
