ZyXEL Communications NWA-3160 Series - Manual (Page 251)

ZyXEL NWA-3160 Series User’s Guide
251
A
P P E N D I X
A
Product Specifications
The following tables summarize the ZyXEL Device’s hardware and firmware features.
Table 94 Hardware Specifications
SPECIFICATION DESCRIPTION
Dimensions 190x 135 x 40 mm
Weight 420g
Power 12V DC, 1.5 A max. (There is no tolerance for the DC input voltage.)
Ethernet Ports Auto-negotiating: 10 Mbps or 100 Mbps in either half-duplex or full-duplex
mode.
Auto-crossover: Use either crossover or straight-through Ethernet cables.
Power over Ethernet
(PoE)
IEEE 802.3af compliant.
Console Port One MIL-C-5015 style RS-232 console port
(PS/2 connector; Mini Din 6-pin)
Antenna Specifications NWA-3160: Two 2dBi Dual Band (2.4 GHz/5 GHz) attachable dipole
antennas.
NWA-3163: Two 3dBi 2.4GHz attachable dipole antennas.
Output Power NWA-3160:
IEEE 802.11b/g
54Mbps: 16dBm
24Mbps: 17dBm
6Mbps: 18dBm
11Mpbs: 18dBm
IEEE 802.11a
54Mbps: 12dBm
24Mbps: 12dBm
6Mbps: 14dBm
11Mpbs: 14dBm
NWA-3163:
IEEE 802.11b/g
54Mbps: 20dBm
24Mbps: 21dBm
11Mpbs: 23dBm
6Mbps: 23dBm
Operating Environment Temperature: 5º C ~ 50º C
Humidity: 10% ~ 90% RH
Storage Environment Temperature: -25º C ~ 60º C
Humidity: 5% ~ 95% RH
