Chapter 3 Status Screens
ZyXEL NWA-3160 Series User’s Guide
46
Model This field displays the ZyXEL Device’s exact model name.
Firmware Version This field displays the current version of the firmware inside the device. It
also shows the date the firmware version was created. You can change the
firmware version by uploading new firmware in Maintenance > F/W
Upload.
System Up Time This field displays the elapsed time since the ZyXEL Device was turned on.
Current Date Time This field displays the date and time configured on the ZyXEL Device. You
can change this in the System > Time Setting screen.
WLAN Operating
Mode
This field displays the current operating mode of the first wireless module
(AP, Bridge / Repeater, AP + Bridge or MBSSID). You can change the
operating mode in the Wireless > Wireless screen.
Management VLAN This field displays the management VLAN ID if VLAN is active, or
Disabled if it is not active. You can enable or disable VLAN, or change the
management VLAN ID, in the VLAN > Wireless VLAN screen.
IP This field displays the current IP address of the ZyXEL Device on the
network.
LAN MAC This displays the MAC (Media Access Control) address of the ZyXEL
Device on the LAN. Every network device has a unique MAC address
which identifies it across the network.
WLAN MAC This displays the MAC address of the wireless module.
System Resources
Flash This field displays the amount of the ZyXEL Device’s flash memory
currently in use. The flash memory is used to store firmware and SSID
profiles.
Memory This field displays what percentage of the ZyXEL Device’s volatile memory
is currently in use. The higher the memory usage, the more likely the
ZyXEL Device is to slow down. Some memory is required just to start the
ZyXEL Device and to run the web configurator.
CPU This field displays what percentage of the ZyXEL Device’s processing
ability is currently being used. The higher the CPU usage, the more likely
the ZyXEL Device is to slow down.
WLAN Associations This field displays the number of wireless clients currently associated with
the wireless module. Each wireless module supports up to 128 concurrent
associations.
Interface Status
Interface This column displays each interface of the ZyXEL Device.
Status This field indicates whether or not the ZyXEL Device is using the interface.
For each interface, this field displays Up when the ZyXEL Device is using
the interface and Down when the ZyXEL Device is not using the interface.
Rate For the LAN port this displays the port speed and duplex setting.
For the WLAN interface, it displays the downstream and upstream
transmission rate or N/A if the interface is not in use.
SSID Status
SSID This field displays the SSID(s) currently used by the wireless module.
BSSID This field displays the MAC address of the wireless adaptor.
Security This field displays the type of wireless security used by each SSID.
Table 3 The Status Screen
LABEL DESCRIPTION
