Chapter 23 System Information and Diagnosis
ZyXEL NWA-3160 Series User’s Guide
224
Figure 154 Menu 24.1 System Maintenance: Status
The following table describes the fields present in this menu.
Menu 24.1 - System Maintenance - Status 00:15:06
Sat. Jan. 01, 2000
Port Status TxPkts RxPkts Cols Tx B/s Rx B/s Up Time
Ethernet 100M/Full 761 366 0 305 192 0:15:01
WLAN1 54M 515 0 0 64 0 0:15:04
WLAN2 Down 0 0 0 0 0 0:00:00
Port Ethernet Address IP Address IP Mask DHCP
Ethernet 00:19:CB:1C:08:2A 192.168.1.2 255.255.255.0 None
WLAN1 00:19:CB:1C:08:2A
WLAN2 00:00:00:00:00:00
System up Time: 0:15:09
ZyNOS F/W Version: V3.60(AAL.0)b1 | 04/13/2007
Name: NWA-Series
Press Command:
COMMANDS: 9-Reset Counters ESC-Exit
Table 85 Menu 24.1 System Maintenance: Status
FIELD DESCRIPTION
Port This is the port type. Port types are: Ethernet, WLAN1 and WLAN2. WLAN2 is not
supported.
Status This shows the status of the remote node.
TxPkts This is the number of transmitted packets to this remote node.
RxPkts This is the number of received packets from this remote node.
Cols This is the number of collisions on this connection.
Tx B/s This shows the transmission rate in bytes per second.
Rx B/s This shows the receiving rate in bytes per second.
Up Time This is the time this channel has been connected to the current remote node.
Ethernet Address This shows the MAC address of the port.
IP Address This shows the IP address of the network device connected to the port.
IP Mask This shows the subnet mask of the network device connected to the port.
DHCP This shows the DHCP setting (None or Client) for the port.
System Up Time This is the time the ZyXEL Device is up and running from the last reboot.
ZyNOS F/W Version Refers to the ZyNOS (ZyXEL Network Operating System) system firmware version. ZyNOS
is a registered trademark of ZyXEL Communications Corporation.
Name This displays the device name.
