Printing
ColorQube 8570/8870 Color Printer
User Guide 94
Binding Edge Options
When you select automatic 2-sided printing, you can select the binding edge. The binding edge
determines how the pages turn. The actual outcome depends on the orientation (portrait or
landscape) of images on the page, as displayed in the following illustrations.
The default is for the binding to be on the side edge (long end). You can also select short edge as the
binding edge.
Printing a 2-Sided Document Automatically
1. Insert paper in the tray.
•
If you are using Tray 1: Insert side one faceup with the bottom of the page entering the
printer first.
Portrait Landscape
Bind on Side Edge
Flip on Long Edge Bind on Top Edge
Flip on Short Edge Bind on Side Edge
Flip on Short Edge Bind on Top Edge
Flip on Long Edge
8X70-106
