Printing
ColorQube 8570/8870 Color Printer
User Guide
72
6.
At the Short Edge menu, do the following:
•
If the correct short edge size is displayed as the current setup, press OK. Go to step 8.
•
If the correct short edge size is not displayed, select Change > OK. To enter a new short edge
size, use the Up and Down Arrow buttons to specify the envelope’s short edge size and then
press OK.
7.
At the Long Edge menu, do the following:
•
If the correct long edge size is displayed as the current setup, press OK. Go to step 8.
•
If the correct long edge size is not displayed, select Change > OK. To enter a new long edge
size, use the Up and Down Arrow buttons to specify the envelope’s long edge size and then
press OK.
8.
At the Tray 1 Paper Type menu, select Envelope > OK.
9.
In the printer driver, select either Envelope as the paper type or Tray 1 as the paper source.
Printing on Envelopes from Tray 2, 3, 4, or 5
1.
Remove the tray from the printer and position its paper guides. For details, see
2.
Insert no more than 40 envelopes into the tray, flap side down with the flap toward the right side
of the tray as shown.
3.
Adjust the paper guides to fit the envelopes.
Note:
When the paper guides are adjusted correctly, there may be a small space between the
envelopes and the guides.
8X70-109
8X70-117
