TANDBERG 1700 MXP
USER GUIDE

Use the horizontal Arrow keys to navigate in the menu line
and press OK to enter a submenu.
Operating Principles
Getting Acquainted with the System
Basic Menu Navigation Rules

Pick up the remote control to wake up the system or
press OK to display the main menu line.

Use the Arrow keys to navigate in the submenu.

The menu line will be displayed.

Once a topic has been selected, press OK to enter
that topic. Navigate as described above.
Entering Alphanumeric Information

To go deeper into the menu structure, all menus with an
arrow appended allow you to enter a submenu by means
of the
OK or Right Arrow key. Navigate as before.
Editing a Setting Using Radio Buttons
Touch tones Snapshot
Camera Presets
Note! Your administrator may have password
protected the Control Panel . However, this does not
change the principles of operation explained here.
Touch tones Snapshot
Camera Presets
Touch tones Snapshot
Camera Presets
Touch tones Snapshot
Camera Presets
There are Three Ways to Leave a Menu
Cancel . Select this icon to leave
menu undoing any changes.
Select this icon to
Restore Default
Settings .
Save . Select this icon and press OK
to leave the menu putting changes
into effect.
This little icon ( abc ) indicates that the system expects
alphanumeric text entry. Consequently, the (otherwise)
numerical keypad is set to alphanumeric mode. Press
#
to switch between upper case ( ABC ) and lower case ( abc )
letters. Press and hold # to switch between purely numerical
( 123 ) and alphanumerical ( abc / ABC ) functionality.
More on this can be found in Numerical Keypad Features .
Radio buttons, use Horizontal Arrow keys to select the
appropriate setting. Press OK to select a setting.
Touch tones Snapshot
Camera Presets
