SIP Settings (I)
Control Panel > Network Settings > LAN Settings
Touch tones
Snapshot
Camera Presets
CANCEL
Select this icon and press
OK
to leave the menu undoing any
changes.
RESTORE DEFAULTS
Select this icon and press
OK
to restore the default settings.
SAVE & RESTART
Select this icon and press
OK
to leave the menu restarting
the system to put IP Setting
changes into effect.
SAVE
Select this icon and press
OK
to leave
the menu saving the changes. Note
that restart is needed to put changes
into effect here!
MODE
On
. Setting the SIP mode to on will enable the
system for incoming and outgoing SIP calls.
Off
. Setting the SIP mode to off will disable in-
coming and outgoing SIP calls from the system.
DISPLAY NAME
The Display name part of the SIP Address (URI)
is usually a full name or system name.
Examples:
“Alice Wonderland” “System 01”
SIP ADDRESS
The SIP Address is the SIP URI used to address
the system.
Examples:
“1234” “[email protected]”
SERVER DISCOVERY
Auto
. When selected, the SIP Server address
is obtained using Dynamic Host Configuration
Protocol (DHCP).
Manual
. When selected, the manually config-
ured SIP Server address will be used.
SERVER ADDRESS
The Server Address is the manually configured
address for the outbound proxy and registrar.
It is possible to use a fully qualified domain
name, or an IP address. The default port is
5060 for TCP and UDP, but another one can be
provided.
Examples:
“sipserver.example.com”
“sipserver.example.com:5060” “10.0.0.2”
“10.0.0.2:5061”
AUTHENTICATION
User Name
. This is the user name part of the
credentials used to authenticate toward the SIP
Server.
PASSWORD
This is the password part of the credentials
used to authenticate toward the SIP Server.
Lower part of the menu is
explained on the following pages.
