Configuring External Interfaces
6. Turn FUNCTION NUMBER to select the function of the device
that will be triggered by a trigger message on the Peripheral II
bus.
7. Use the LEVEL soft knob to select which E-MEM level will
activate the selected trigger.
For a DPM-700, these functions depend on whether the DPM is
operating in trigger mode or E-MEM recall mode, as listed in
Table 2-1 .
8. Press the main menu CONFG button to return to the
Configuration Menu.
Table 2-1. DPM-700 Trigger Functions
Trigger DPM Trigger Function DPM E-MEM Recall
0 Function not defined Not valid
1 STOP DPM RECALL REGISTER 1
2 RUN DPM RECALL REGISTER 2
3 NEXT KEYFRAME DPM RECALL REGISTER 3
4 PREVIOUS KEYFRAME DPM RECALL REGISTER 4
5 STOP NEXT DPM RECALL REGISTER 5
6 REVERSE DPM RECALL REGISTER 6
7 REWIND DPM RECALL REGISTER 7
8 KEYER AUTO-TRANS DPM RECALL REGISTER 8
9 KEYER CUT DPM RECALL REGISTER 9
10 FADE TO BLACK AUTO-TRANS DPM RECALL REGISTER 10
11 FADE TO BLACK CUT DPM RECALL REGISTER 11
12 COMBINER AUTO-TRANS DPM RECALL REGISTER 12
13 COMBINER CUT DPM RECALL REGISTER 13
14 Function not defined DPM RECALL REGISTER 14
15 Function not defined DPM RECALL REGISTER 15
