Assigning Peripheral Triggers
This menu allows you to configure up to eight peripheral triggers
for the switcher (designated A through H). Each trigger is sent to
a particular address (Device Number) on the Peripheral Bus.
Once configured, these triggers can be learned into E-MEM effects
(on
MISC or DPM 1–4 levels) or fired directly from this menu. Refer
to the Keyframe/Attach Peripheral Trigger Menu description in
the Operator’s Guide for attaching peripheral triggers to E-MEM
registers.
3. From the Peripheral Interface Menu, press PERIPHERAL
TRIGGERS> to open the Peripheral Triggers Menu.
4. Increment TRIGGER SELECT to select the trigger to be
configured (A through H).
5. Turn the DEVICE NUMBER soft knob to select the peripheral
device to which that trigger will be sent.
PERIPHERAL TRIGGERS MENU
config / extern if / peripheral if / peripheral triggers
TRIGGER
SELECT
FIRE
B
LEVEL
= DPM 1
FUNCTION NUMBER
= 4
A
C
D
E
F
G
H
DEVICE NO.
-
-
-
-
-
-
-
FUNCTN NO.
-
-
-
-
-
-
-
LEVEL
-
-
-
-
-
-
-
B
1 4 B DPM 1
DEVICE NUMBER
= 1
