Appendix A — Shaped and Unshaped Video
A-10
shows what the video looks like on the monitor when
the input fill video is shaped, but
UNSHAPED
is selected in the
Map Inputs menu.
Figure A-9. Incorrect Video With Shaped Input and UNSHAPED Selected
Note dark
halo effect.
