Output Shaped and Unshaped Video
A-15
For the Model 4000 or Model 2200:
1. Press the CONFG button on the switcher’s main menu panel,
then the AUX BUS FORMAT> soft button in the Configuration
menu, and the AUX BUS SHAPING> button in the Aux Bus
Format menu to bring up the Aux Bus Shaping menu, shown
in
Figure A-13 .
2. Set the VIDEO/KEY FMT selections for Aux Buses 1 through 4
(Aux 1 and 2 on the 2200) to match the characteristic SHAPED
or UNSHAPED expected by the external devices connected to
those outputs. These settings control the states of the
unshapers on the Aux Bus outputs.
When the Effects Send option is not present, the VIDEO/KEY
FMT selections are not visible in the menu.
Figure A-13. Model 4000 and Model 2200 Aux Bus Shaping Menu (Software v5.0)
AUX BUS SHAPING MENU
config/aux bus format/aux bus shaping
LOGICAL PHYSICAL
PHYS AUX
SELECT
VIDEO/
KEY FMT
AUX 1
AUX BUS 2
AUX BUS 3
AUX BUS 4
UNSHAPED
UNSHAPED
UNSHAPED
AUX BUS 2
AUX BUS 3
AUX BUS 4
AUX BUS 1 SHAPED AUX BUS 1
UNSHAPED
SHAPED
