4-49
E-MEM (Effects Memory) Operations
Learn Enables
An E-MEM register can store all switcher functions, or part of
them, as determined by the E-MEM Enable buttons.
M/E 1 and
PGM/PST will be used for this procedure. In this procedure you
will ‘learn’ an effect into E-MEM register 23.
1. Press AUTO RCL (Auto Recall) (button lit). This causes all
Enabled buttons to be learned as part of the effect.
2. Press E-MEM Subpanel Enables buttons M/E 1 and PGM/PST
(buttons light). (You should have an effect set up on M/E 1.
You may want to have sources selected on the M/E 1 ‘A’ and
‘B’ buses; one source selected on the PGM bus; and M/E 1
selected on the PST bus.)
3. Press LRN , BANK , 2 , 3 to learn this current switcher panel
setup and crosspoints into register number 23.
Recall Enables
1. Change the crosspoints on M/E 1.
2. Ensure that AUTO RCL is on.
3. Select register 23. ( BANK , 2 , 3 .)
4. Observe the recalled effect on the Program monitor.
