2-4
Section 2 — Startup & Configuration
2. Press the INSTALL INFO> soft button to bring up the Main
Boards Menu:
This menu shows the functions of all the slots in the center card
cage (Bay B). Each slot that has a module installed indicates the
presence of the module by listing its assembly/version number.
(No assembly/version is shown for the Control Processor module
in cell 17 because it is unable to interrogate itself. However, you
can be sure that it is present and operating; otherwise you would
not have made it to this point.)
Entries that have a “-” in the left column are mezzanine boards
that might be installed on the modules listed immediately above
them in the table.
Note that the version of the installed software is displayed in the
upper right-hand corner of the display.
INSTALLATION INFO MENU
status / install info
UPPER
BOARDS
LOWER
BOARDS
MODEL 3000-3 SOFTWARE VERSION: 5.0
SLOT
1
-
2
-
3
-
4
-
-
5
-
-
BOARD
M1 CK
DECODER
M2 CK
DECODER
M3 CK
DECODER
M1 KEYER
K1 BDL
K2 BDL
M2 KEYER
K1 BDL
K2 BDL
VERSION
068907-01A
068943-228
068907-01A
068943-228
068907-01A
068943-228
068904-01D
068915-00A
068915-00A
068904-01D
068915-00A
068915-00A
SLOT
13
-
14
-
15
16
-
-
17
BOARD
M2 MIX/WIPE
PVW DIM
M1 MIX/WIPE
PVW DIM
SEC WIPE
PGM/PST/DSK
K1 BDL
K2 BDL
CTRL PROC
VERSION
068903-08I
068942-00A
068903-08I
068942-00A
068912-00C
068905-00F
068915-00A
068915-00A
SLOT
6
-
-
7
-
8
9
10
-
11
12
-
BOARD
M3 KEYER
K1 BDL
K2 BDL
SYNC
SAFE TITLE
XPT HI
XPT LO
FRAME STORE
DECODER
EFX SEND
M3 MIX/WIPE
PVW DIM
VERSION
068904-01D
068915-00A
068915-00A
068901-00K
068917-00B
068900-00A
068900-00A
068911-00D
068903-08I
068942-00A
MAIN
BOARDS
