4-15
Wipe Operations
Pattern Mixing
Use the Pattern Mix Mode to mix a selected wipe with either the
M/Es Secondary Wipe Generator (if available) or the selected
wipes. This example assumes you have the Secondary Wipe
Generator; if you do not, select
TEXTURE instead of NORMAL in
Step 3.
1. Press the WIPE Top Level Menu button on the Wipe Subpanel.
Press the PATTERN soft button to access the Wipe Pattern
Menu.
2. Select the M/E 1 PRI wipe generator on the Wipe Pattern Menu.
(Optional - GVG Default) Use the PTN MIX SOURCE
button to select NORMAL . (Selects a mix between the
primary and secondary wipe generators.)
3. Select circle pattern number 3. Select M/E 1 SEC and choose
box pattern number 23.
4. Press the M/E 1 Transition Wipe button.
5. Move the Run lever between stops and verify the circle wipe
transitions.
6. Position the lever arm in the middle of its travel.
7. Turn on PATTERN MIX (Wipe Subpanel) and adjust the pattern
mix controls between limits.
AUX
BUS
MATTE
WIPE
DISK
FRAME
STORE
KEYER
MASK
EMEM
M/E
MODE
KEY
FRAME
LAST
MENU
STAT
MISC
CHR
KEY
CONFG
Top Level Menu Buttons
