13.3 LCD Indicators
The operator can scroll through the following lCD display screens using the scroll buttons.
TABLE 13.1 - LCD DISPLAY SCREENS
name
Description
normal Display
Displays operational status, operational guidance, and measured
data.
Fault Display
Displays detailed data when a fault occurs.
warning Display
Displays detailed data when a warning occurs.
FIGURE 13.3 - CHANGING SCREENS WITH SCROLL BUTTONS
SCroll Up
SCroll Down
NORMAL DISPLAY
WARNIG DISPLAY
FAULT DISPLAY
