33 G8000 Series Installation and operation Manual
TABLE 11.4 RECOMMENDED CABLE SIZE AND FASTENER TORQUE FOR 225 KVA UNIT
block number Cable Size recommended Fastener Torque **
1 Two AwG 2/0 or larger 540 in.-lb. (6.2 kg-m)
2 Two AwG 2/0 or larger 540 in.-lb. (6.2 kg-m)
3 Two AwG 2/0 or larger 540 in.-lb. (6.2 kg-m)
4 Two AwG 2/0 or larger 540 in.-lb. (6.2 kg-m)
5 Two AwG 2/0 or larger 540 in.-lb. (6.2 kg-m)
6 Two AwG 2/0 or larger 540 in.-lb. (6.2 kg-m)
7 Two AwG 2/0 or larger 540 in.-lb. (6.2 kg-m)
8 Two AwG 2/0 or larger 540 in.-lb. (6.2 kg-m)
9 Two AwG 2/0 or larger 540 in.-lb. (6.2 kg-m)
10 Two AwG 2/0 or larger 540 in.-lb. (6.2 kg-m)
11 Two AwG 2/0 or larger 540 in.-lb. (6.2 kg-m)
*12 Three AwG 4/0 or larger 540 in.-lb. (6.2 kg-m)
*13 Three AwG 4/0 or larger 540 in.-lb. (6.2 kg-m)
* one battery string. (Consult factory if using more than one battery string.)
** Fastener torque specified for: 1/2 in. diameter grade 5 steel bolt.
TABLE 11.5 RECOMMENDED CABLE SIZE AND FASTENER TORQUE FOR 300 KVA UPS
bus number Cable Size recommended Fastener Torque **
1 Two AwG 4/0 or larger 540 in.-lb. (6.2 kg-m)
2 Two AwG 4/0 or larger 540 in.-lb. (6.2 kg-m)
3 Two AwG 4/0 or larger 540 in.-lb. (6.2 kg-m)
*4 Three 350 MCM or larger 540 in.-lb. (6.2 kg-m)
*5 Three 350 MCM or larger 540 in.-lb. (6.2 kg-m)
6 Two AwG 4/0 or larger 540 in.-lb. (6.2 kg-m)
7 Two AwG 4/0 or larger 540 in.-lb. (6.2 kg-m)
8 Two AwG 4/0 or larger 540 in.-lb. (6.2 kg-m)
9 Two AwG 4/0 or larger 540 in.-lb. (6.2 kg-m)
10 Two AwG 4/0 or larger 540 in.-lb. (6.2 kg-m)
11 Two AwG 4/0 or larger 540 in.-lb. (6.2 kg-m)
12 Two AwG 4/0 or larger 540 in.-lb. (6.2 kg-m)
* one battery string. (Consult factory if using more than one battery string.)
** Fastener torque specified for: 1/2 in. diameter grade 5 steel bolt.
