45 G8000 Series Installation and operation Manual
12.3 Electrical Specification
Nominal Capacity 100 kW 150 kW 225 kW 300 kW
AC Input rated Capacity* 110 kw (120 kw) 165 kw (180 kw) 245 kw (270 kw) 320 kw (320 kw)
Input Voltage 480 V ( +10% to -15% ), 3-phase 3-wire
Input Frequency 60 Hz ±5%
Input power Factor 0.95 – 1.00 lagging ( at 100% load )
Current Harmonic Distortion 4% Maximum ( at 100% load )
Input Capacity required* 111 kVA (124 kVA) 166 kVA (184 kVA) 250 kVA (274 kVA) 327 kVA (332 kVA)
Circuit breaker rating At 480 V
Input
200 A Trip 300 A Trip 450 A Trip 500 A Trip
* Capacity: normal Mode (recharge Mode)
Nominal Capacity 100 kW 150 kW 225 kW 300 kW
DC Input Voltage window 288 – 414 VDC
recharge Voltage regulation ± 1.5%
Nominal Capacity 100 kW 150 kW 225 kW 300 kW
AC output rated Capacity* 100 kVA (100 kw) 150 kVA (150 kw) 225 kVA (225 kw) 300 kVA (300 kw)
output Voltage 480/277 V ± 1%, 3-phase 4-wire
output power Factor 1.0 pF: 32 – 86 °F (0 – 30 °C)
0.8 pF: 86 – 104 °F (30 – 40 °C)
Voltage Distortion 3% with 100% linear load / 5% with non-linear load
Transient Voltage regulation < ± 2%
Transient Settling Time < 50 ms
Crest Factor 2.0
output Frequency 60 Hz ± 0.01% ( at Free-running Mode)
Synchronous window To Utility line 59 Hz – 61 Hz
Frequency Slew rate 1 Hz/Sec
over load rating 100% – Continuous / 125% – 10 min. / 150% – 1 min.
* Capacity: normal Mode (recharge Mode)
WARNING
DO NOT open the front cover.
electric shock, burns or other personal injuries may occur if untrained
personnel open the front cover.
