Rev (Reverb) (p. 120)
Sw On, Off
Type Room1, Room2, Hall1, Hall2, Plate
Gate Off, On
Mode Gate, Ducking
Time 0.1–10.0 sec
PreDLY 0–200 msec
Densty 0–100
HPF Thru, 20–2000 Hz
LPF 1.0–20.0 kHz, Thru
Thresh 0–100
Attack 1–100
Releas 1–100
HoldT 1–100
EfxLvl 0–100
DirLvl 0–100
EQ (Equalizer) (p. 110)
Sw Off, On
Low Gain -12–12 dB
Low Freq 20–2000 Hz
Low Q 0.3–10.0
Low Type Shlv, Peak
Mid Gain -12–12 dB
Mid Freq 200–8000 Hz
Mid Q 0.3–10.0
High Gain -12–12 dB
High Freq 1.4–20.0 kHz
High Q 0.3–10.0
Hi Type Shlv, Peak
Level 0–100
VS8F-2 Algorithm List
99
Reverb 2
This is a reverb that provides a gating function and a ducking function. It can be used in
whichever EFX1 to EFX4. You can use two reverbs with different settings, or use it in
combination with a previous reverb.
fig.ap(efx)-43(rev2_blk.eps)
Reverb
Equalizer
Equalizer
Input L
Input R
Direct Level
Direct Level
Output L
Output R
