| 01 00 17 | 00 - 3B | (minute) |
| 01 00 18 | 00 - 17 | (hour) |
| 01 00 19 | 00 - 07 | (a day of week) |
| 01 00 1A | 00 - 1F | (day) |
| 01 00 1B | 00 - 0C | (month) |
| 01 00 1C | 0aaaaaaa| |
| 01 00 1D#| 0bbbbbbb| (year) |
|——————————+—————————+————————————————————————————————————————————|
| 01 00 1E | 00 | (Reserved) |
|——————————+—————————+————————————————————————————————————————————|
| 01 00 1F | 00 | (Reserved) |
|——————————+—————————+————————————————————————————————————————————|
| 01 00 20 | 00 - xx | Current Song Protect Off, On(=01 or 81) |
|——————————+—————————+————————————————————————————————————————————|
| 01 00 21 | 00 | (Reserved) |
|——————————+—————————+————————————————————————————————————————————|
| 01 00 22 | 0000000a| Song List Length abbbbbbb = 1,,,200 |
| 01 00 23#| 0bbbbbbb| |
|——————————+—————————+————————————————————————————————————————————|
| 01 00 24 | 00 | (Reserved) |
| : | : | : |
| 01 00 7F | 00 | (Reserved) |
|——————————+—————————+————————————————————————————————————————————|
| 01 01 00 | 20 - 7E | Current Song Comment - 1 (ASCII)|
| : : : |
| 01 01 63 | 20 - 7E | Current Song Comment -100 (ASCII)|
|——————————+—————————+————————————————————————————————————————————|
| 01 01 64 | 00 | (Reserved) |
| : : : |
| 01 01 7D | 00 | (Reserved) |
|——————————+—————————+————————————————————————————————————————————|
| 01 02 00 | 00 - | Song- 1 (similar to 01 00 00 - 01 00 1F) |
| : | : | : |
| 01 02 1F | 00 - | |
|——————————+—————————+————————————————————————————————————————————|
| : | : | : |
| 01 33 60 | 00 - | Song-200 (similar to 01 00 00 - 01 00 1F) |
| : | : | : |
| 01 33 7F | 00 - | |
|——————————+—————————+————————————————————————————————————————————|

(*) The address marked by “#” are invalid. Request to Data Request (RQ1) message with
the specified size to the address without “#” mark.
(*) Only the Data Set (DT1) message to the song nameand song comment is acceptable.

● Mixer Parameter

+—————————————————————————————————————————————————————————————————+
| Start | | |
| address | Data | Contents and remarks |
|==========+=========+============================================|
| 02 00 00 | 00 - | Track Status -1 |
| | | 00=SOURCE,01=PLAY,02=REC |
| | | 40=SOURCE_MUTE,41=PLAY_MUTE, |
| | | 22=REC_SOURCE |
| : | : | : |
| 02 00 0F | 00 - | Track Status -16 |
|——————————+—————————+————————————————————————————————————————————|
| 02 00 10 | 00 - 0f | V.Track -1 1,,,16 |
| : | : | : |
| 02 00 1F | 00 - 0f | V.Track -16 |
|——————————+—————————+————————————————————————————————————————————|
| 02 00 20 | 00 - | (Reserved) 0 |
| : | : | |
| 02 00 3F | 00 - | |
|——————————+—————————+————————————————————————————————————————————|
| 02 00 40 | 00 - 08 | Track Channel ATT -1 |
| | | -42,-36,-30,-24,-18,-12,-6,0,+6dB |
| : | : | : |
| 02 00 4F | 00 - 08 | Track Channel ATT -16 |
|——————————+—————————+————————————————————————————————————————————|
| 02 00 50 | 00 - 08 | Input Channel ATT -1 |
| | | -42,-36,-30,-24,-18,-12,-6,0,+6dB |
| : | : | : |
| 02 00 59 | 00 - 08 | Input Channel ATT -10 |
|——————————+—————————+————————————————————————————————————————————|
| 02 00 5A | 00 - | (dummy) |
| : | : | |
| 02 00 5F | 00 - | |
|——————————+—————————+————————————————————————————————————————————|
| 02 00 60 | 00 - 01 | Track Channel Phase -1 Nor,Inv |
| : | : | : |
| 02 00 6F | 00 - 01 | Track Channel Phase -16 |
|——————————+—————————+————————————————————————————————————————————|
| 02 00 70 | 00 - 01 | Input Channel Phase -1 Nor,Inv |
| : | : | : |
| 02 00 79 | 00 - 01 | Input Channel Phase -10 |
|——————————+—————————+————————————————————————————————————————————|
| 02 00 7A | 00 - | (dummy) |
| : | : | |
| 02 00 7F | 00 - | |
|——————————+—————————+————————————————————————————————————————————|
| 02 01 00 | 00 - | (Reserved) 0 |
| : | : | |
| 02 01 1F | 00 - | |
|——————————+—————————+————————————————————————————————————————————|
| 02 01 20 | 00 - 01 | Track Channel EQ Switch -1 Off,On |
| : : : |
| 02 01 2F | 00 - 01 | Track Channel EQ Switch -16 |
|——————————+—————————+————————————————————————————————————————————|
| 02 01 30 | 00 - 01 | Input Channel EQ Switch -1 Off,On |
| : : : |
| 02 01 39 | 00 - 01 | Input Channel EQ Switch -10 |
|——————————+—————————+————————————————————————————————————————————|
| 02 01 3A | 00 - | (dummy) |
| : : |
| 02 01 3F | 00 - | |
|——————————+—————————+————————————————————————————————————————————|
| 02 01 40 | 00 - 7F | Track Channel EQ L Freq.-1 |
| | | 40,50,60,70,80,90,100,120,140, |
| | | 160,180,200,300,400,500, |
| | | 600,700,800,900,1K,1.1K, |

| | | 1.2K,1.3K,1.4K,1.5KHz |
| : | : | : |
| 02 01 4F | 00 - 7F | Track Channel EQ L Freq.-16 |
|——————————+—————————+————————————————————————————————————————————|
| 02 01 50 | 00 - 7F | Input Channel EQ L Freq.-1 |
| | | 40,50,60,70,80,90,100,120, |
| | | 140,160,180,200,300,400,500, |
| | | 600,700,800,900,1K,1.1K, |
| | | 1.2K,1.3K,1.4K,1.5KHz |
| : | : | : |
| 02 01 59 | 00 - 7F | Input Channel EQ L Freq.-10 |
|——————————+—————————+————————————————————————————————————————————|
| 02 01 5A | 00 - | (dummy) |
| : | : | |
| 02 01 5F | 00 - | |
|——————————+—————————+————————————————————————————————————————————|
| 02 01 60 | 00 - 7F | Track Channel EQ L Gain -1 12,,,+12dB |
| : : : |
| 02 01 6F | 00 - 7F | Track Channel EQ L Gain -16 |
|——————————+—————————+————————————————————————————————————————————|
| 02 01 70 | 00 - 7F | Input Channel EQ L Gain -1 12,,,+12dB |
| : : : |
| 02 01 79 | 00 - 7F | Input Channel EQ L Gain -10 |
|——————————+—————————+————————————————————————————————————————————|
| 02 01 7A | 00 - | (dummy) |
| : | : | |
| 02 01 7F | 00 - | |
|——————————+—————————+————————————————————————————————————————————|
| 02 02 00 | 00 - 7F | Track Channel EQ M Freq.-1 |
| | | 200,300,400,500,600,700,800, |
| | | 900,1K,1.1K,1.2K,1.3K,1.4K, |
| | | 1.5K,1.6K,1.7K,1.8K,1.9K,2K, |
| | | 3K,4K,5K,6K,7K,8KHz |
| : | : | : |
| 02 02 0F | 00 - 7F | Track Channel EQ M Freq.-16 |
|——————————+—————————+————————————————————————————————————————————|
| 02 02 10 | 00 - 7F | Input Channel EQ M Freq.-1 |
| | | 200,300,400,500,600,700,800, |
| | | 900,1K,1.1K,1.2K,1.3K,1.4K, |
| | | 1.5K,1.6K,1.7K,1.8K,1.9K,2K, |
| | | 3K,4K,5K,6K,7K,8KHz |
| : | : | : |
| 02 02 19 | 00 - 7F | Input Channel EQ M Freq.-16 |
|——————————+—————————+————————————————————————————————————————————|
| 02 02 1A | 00 - | (dummy) |
| : | : | |
| 02 02 1F | 00 - | |
|——————————+—————————+————————————————————————————————————————————|
| 02 02 20 | 00 - 7F | Track Channel EQ M Gain -1 12,,,+12dB |
| : : : |
| 02 02 2F | 00 - 7F | Track Channel EQ M Gain -16 |
|——————————+—————————+————————————————————————————————————————————|
| 02 02 30 | 00 - 7F | Input Channel EQ M Gain -1 12,,,+12dB |
| : : : |
| 02 02 39 | 00 - 7F | Input Channel EQ M Gain -10 |
|——————————+—————————+————————————————————————————————————————————|
| 02 02 3A | 00 - | (dummy) |
| : | : | |
| 02 02 3F | 00 - | |
|——————————+—————————+————————————————————————————————————————————|
| 02 02 40 | 00 - 7F | Track Channel EQ M Q -1 0.5,1,2,4,8,16 |
| : | : | : |
| 02 02 4F | 00 - 7F | Track Channel EQ M Q -16 |
|——————————+—————————+————————————————————————————————————————————|
| 02 02 50 | 00 - 7F | Input Channel EQ M Q -1 0.5,1,2,4,8,16 |
| : : : |
| 02 02 59 | 00 - 7F | Input Channel EQ M Q -10 |
|——————————+—————————+————————————————————————————————————————————|
| 02 02 5A | 00 - | (dummy) |
| : | : | |
| 02 02 5F | 00 - | |
|——————————+—————————+————————————————————————————————————————————|
| 02 02 60 | 00 - 7F | Track Channel EQ H Freq.-1 |
| | | 500,600,700,800,900,1K,1.2K, |
| | | 1.4K,1.6K,1.8K,2K,3K,4K,5K, |
| | | 6K,7K,8K,9K,10K,11K,12K, |
| | | 13K,14K,16K,18KHz |
| : | : | : |
| 02 02 6F | 00 - 7F | Track Channel EQ H Freq.-16 |
|——————————+—————————+————————————————————————————————————————————|
| 02 02 70 | 00 - 7F | Input Channel EQ H Freq.-1 |
| | | 500,600,700,800,900,1K,1.2K, |
| | | 1.4K,1.6K,1.8K,2K,3K,4K,5K, |
| | | 6K,7K,8K,9K,10K,11K,12K, |
| | | 13K,14K,16K,18KHz |
| : | : | : |
| 02 02 79 | 00 - 7F | Input Channel EQ H Freq.-10 |
|——————————+—————————+————————————————————————————————————————————|
| 02 02 7A | 00 - | (dummy) |
| : | : | |
| 02 02 7F | 00 - | |
|——————————+—————————+————————————————————————————————————————————|
| 02 03 00 | 00 - 7F | Track Channel EQ H Gain -1 12,,,+12dB |
| : | : | : |
| 02 03 0F | 00 - 7F | Track Channel EQ H Gain -16 |
|——————————+—————————+————————————————————————————————————————————|
| 02 03 10 | 00 - 7F | Input Channel EQ H Gain -1 12,,,+12dB |
| : | : | : |
| 02 03 19 | 00 - 7F | Input Channel EQ H Gain -10 |
|——————————+—————————+————————————————————————————————————————————|
| 02 03 1A | 00 - | (dummy) |
| : | : | |
| 02 03 1F | 00 - | |
|——————————+—————————+————————————————————————————————————————————|
| 02 03 20 | 00 - 04 | Track Channel Effect 1 Insert Switch -1 |
| | | Off,Ins,InsL,InsR,InsS |
| : | : | : |
| 02 03 2F | 00 - 04 | Track Channel Effect 1 Insert Switch -16 |
|——————————+—————————+————————————————————————————————————————————|
| 02 03 30 | 00 - 04 | Input Channel Effect 1 Insert Switch -1 |
| | | Off,Ins,InsL,InsR,InsS |
| : | : | : |
| 02 03 39 | 00 - 04 | Input Channel Effect 1 Insert Switch -10 |
|——————————+—————————+————————————————————————————————————————————|
| 02 03 3A | 00 - | (dummy) |
| : | : | |
| 02 03 3F | 00 - | |

MIDI Implementation

38
