Input Mixer
* If Stereo Link is On, the “Pan” parameter will change to the balance parameter.
* If two VS8F-2 (s) are installed in your VS-1680, the “AUX1” will change to the “EFX1,” the “AUX2” will change to the
“EFX2,” the “AUX3” will change to the “AUX.”
Parameter name Display Value Initial value
Master Send Pan/Balance Pan L63–0–R63 0
Equalizer Switch EQ Sw Off, On Off
Equalizer Select - 2 Band EQ, 3 Band EQ 2 Band EQ
Equalizer Low Gain Low G -12–12 dB 0 dB
Equalizer Low Frequency Low F 40 Hz–1.5 kHz 300 Hz
Equalizer Mid Gain Mid G -12–12 dB 0 dB (*1)
Equalizer Mid Frequency Mid F 200 Hz–8 kHz 1.4 kHz (*1)
Equalizer Mid Q Mid Q 0.5–16 0.5 (*1)
Equalizer High Gain High G -12–12 dB 0 dB
Equalizer High Frequency High F 500 Hz–18 kHz 4 kHz
Effect Switch (1–2) EFX* (1–2) Off, Pre, Pst Off
Effect Send Level - 0–127 100 (*2)
Effect Pan/Balance - L63–0–R63 0 (*2)
AUX Switch AUX* (1–3) Off, Pre, Pst Off
AUX Level - 0–127 100 (*3)
AUX Pan/Balance - L63–0–R63 0 (*3)
Effect Insert Switch (1–4) EFXIns (1–4) Off, Ins, InsL, InsR, InsS Off
Effect Insert Send Level (1–4) Snd -42–6 dB 0 dB (*4)
Effect Insert Return Level (1–4) Rtn -42–6 dB 0 dB (*4)
Stereo Link Link Off, On Off
Attenuation ATT -42–6 dB 0 dB
Phase Phase NRM, INV NRM
Level Meter Meter Pre, Pst Pre
Solo Solo Off, On Off
Mute Mute Off, On Off
Fader Fader 0–127 100
*1 Valid when Equalizer Select is “3 Band EQ.”
*2 Valid when Effect Switch is except “Off.”
*3 Valid when AUX Switch is except “Off.”
*4 Valid when Effect Insert Switch is except “Off.”
Parameter List
