| 04 00 22 | 0aaaaaaa| Tape Echo Tape Head L Pan |
| 04 00 23#| 0bbbbbbb| 1,,,127 = L63,,,R63|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 24 | 0aaaaaaa| Tape Echo Tape Distortion |
| 04 00 25#| 0bbbbbbb| 0,,,100|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 26 | 0aaaaaaa| Tape Echo Wah Flutter Rate |
| 04 00 27#| 0bbbbbbb| 0,,,100|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 28 | 0aaaaaaa| Tape Echo Wah Flutter Depth |
| 04 00 29#| 0bbbbbbb| 0,,,100|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 2A | 00 | (Reserved) |
| : | : | |
| 04 00 7F | 00 | |
+——————————+—————————+————————————————————————————————————————————+
✧ Algorithm 32 Analog Flanger
+——————————+—————————+————————————————————————————————————————————+
| 04 00 0E | 0aaaaaaa| Analog Flanger SW |
| 04 00 0F#| 0bbbbbbb| 0,1 = Off,On|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 10 | 0aaaaaaa| Analog Flanger Mode |
| 04 00 11#| 0bbbbbbb| 0,,,3 = FL1,FL2,FL3,CHO|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 12 | 0aaaaaaa| Analog Flanger Feedback |
| 04 00 13#| 0bbbbbbb| 0,,,100|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 14 | 0aaaaaaa| Analog Flanger Modulation Rate |
| 04 00 15#| 0bbbbbbb| 0,,,100|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 16 | 0aaaaaaa| Analog Flanger Modulation Depth |
| 04 00 17#| 0bbbbbbb| 0,,,100|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 18 | 0aaaaaaa| Analog Flanger Modulation Frequency |
| 04 00 19#| 0bbbbbbb| 0,,,100|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 1A | 0aaaaaaa| Analog Flanger Channel B Modulation |
| 04 00 1B#| 0bbbbbbb| 0,1 = Nor,Inv|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 1C | 0aaaaaaa| Analog Flanger Channel A Phase |
| 04 00 1D#| 0bbbbbbb| 0,1 = Nor,Inv|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 1E | 0aaaaaaa| Analog Flanger Channel B Phase |
| 04 00 1F#| 0bbbbbbb| 0,1 = Nor,Inv|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 20 | 00 | (Reserved) |
| : | : | |
| 04 00 7F | 00 | |
+——————————+—————————+————————————————————————————————————————————+
✧ Algorithm 33 Analog Phaser
+——————————+—————————+————————————————————————————————————————————+
| 04 00 0E | 0aaaaaaa| Analog Phaser SW |
| 04 00 0F#| 0bbbbbbb| 0,1 = Off,On|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 10 | 0aaaaaaa| Analog Phaser Mode |
| 04 00 11#| 0bbbbbbb| 0,1 = 4STAGE,8STAGE|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 12 | 0aaaaaaa| Analog Phaser Frequency |
| 04 00 13#| 0bbbbbbb| 0,,,100|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 14 | 0aaaaaaa| Analog Phaser Resonance |
| 04 00 15#| 0bbbbbbb| 0,,,100|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 16 | 0aaaaaaa| Analog Phaser LFO 1 Rate |
| 04 00 17#| 0bbbbbbb| 0,,,100|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 18 | 0aaaaaaa| Analog Phaser LFO 1 Depth |
| 04 00 19#| 0bbbbbbb| 0,,,100|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 1A | 0aaaaaaa| Analog Phaser LFO 1 Channel B Mod |
| 04 00 1B#| 0bbbbbbb| 0,1 = Nor,Inv|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 1C | 0aaaaaaa| Analog Phaser LFO 2 Rate |
| 04 00 1D#| 0bbbbbbb| 0,,,100|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 1E | 0aaaaaaa| Analog Phaser LFO 2 Depth |
| 04 00 1F#| 0bbbbbbb| 0,,,100|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 20 | 0aaaaaaa| Analog Phaser LFO 2 Channel B Mod |
| 04 00 21#| 0bbbbbbb| 0,1 = Nor,Inv|
|——————————+—————————+————————————————————————————————————————————|
| 04 00 22 | 00 | (Reserved) |
| : | : | |
| 04 00 7F | 00 | |
+——————————+—————————+————————————————————————————————————————————+
● Sync Track Data
+—————————————————————————————————————————————————————————————————+
| Start | | |
| address | Data | Contents and remarks |
|==========+=========+============================================|
| 08 00 00 | 0000aaaa| Sync Track Data 1 |
| 08 00 01 | 0000bbbb| aaaabbbbccccdddd |
| 08 00 02 | 0000cccc| |
| 08 00 03 | 0000dddd| |
|——————————+—————————+————————————————————————————————————————————|
| 08 00 04 | 0000aaaa| Sync Track Data 2 |
| 08 00 05 | 0000bbbb| aaaabbbbccccdddd |
| 08 00 06 | 0000cccc| |
| 08 00 07 | 0000dddd| |
|——————————+—————————+————————————————————————————————————————————|
| 08 00 08 | 0000aaaa| Sync Track Data 3 |
| : | : | : |
| 0F 7f 7B | 0000dddd| Sync Track Data 32767 |
|——————————+—————————+————————————————————————————————————————————|
| 0F 7F 7C | 0000aaaa| Sync Track Data 32768 |
| 0F 7F 7D | 0000bbbb| aaaabbbbccccdddd |
| 0F 7F 7E | 0000cccc| |
| 0F 7F 7F | 0000dddd| |
+——————————+—————————+————————————————————————————————————————————+
3. MIDI Machine Control
■ MIDI Machine Control Details
● STOP(MCS)
Status Data Byte Status
F0H 7FH,Dev,06H,01H F7H
Byte Description
F0H Status of System Exclusive Message
7FH Universal System Exclusive Message Realtime Header
Dev Device ID (or 7FH)
06H MMC Command Message
01H STOP (MCS)
F7H EOX (End of System Exclusive Message)
If the device ID on the message was as same as that of the receiving device or 7FH, the VS-
1680 stops immediately. If the transport switch [STOP] was pressed, the VS-1680 transmits
as the device ID 7FH.
● PLAY(MCS)
Status Data Byte Status
F0H 7FH,Dev,06H,02H F7H
Byte Description
F0H Status of System Exclusive Message
7FH Universal System Exclusive Message Realtime Header
Dev Device ID (or 7FH)
06H MMC Command Message
02H PLAY (MCS)
F7H EOX (End of System Exclusive Message)
If the device ID on the message was as same as that of the receiving device or 7FH, the VS-
1680 goes into the playback condition. The VS-1680 does not transmit this message.
● DEFERRED PLAY(MCS)
Status Data Bytes Status
F0H 7FH,Dev,06H,03H F7H
Byte Description
F0H Status of System Exclusive Message
7FH Universal System Exclusive Message Realtime Header
Dev Device ID (or 7FH)
06H MMC Command Message
03H DEFERRED PLAY (MCS)
F7H EOX (End of System Exclusive Message)
If the device ID on the message was as same as that of the receiving device or 7FH, the VS-
1680 goes into the playback condition after the locate operation. If the transport switch
[PLAY] was pressed, the VS-1680 transmits as the device ID 7FH.
● FAST FORWARD(MCS)
Status Data Bytes Status
F0H 7FH,Dev,06H,03H F7H
Byte Description
F0H Status of System Exclusive Message
7FH Universal System Exclusive Message Realtime Header
Dev Device ID (or 7FH)
06H MMC Command Message
03H DEFERRED PLAY (MCS)
F7H EOX (End of System Exclusive Message)
If the device ID on the message was as same as that of the receiving device or 7FH, the VS-
1680 goes into the fast forward condition. The VS-1680 does not transmit the message.
