NS (Noise Suppressor) (p. 115)
Sw Off, On
Thresh 0–100
Release 0–100
Cmp (Compressor/Limiter) (p. 114)
Sw Off, On
Thresh -60–0 dB
Ratio 1.5:1, 2:1, 4:1, 100:1,
Attack 0–100
Release 0–100
Level -60–12 dB
Enh (Enhancer) (p. 117)
Sw Off, On
Sens 0–100
Freq 1.0–10.0 kHz
MixLvl 0–100
Level 0–100
EQ (Equalizer) (p. 110)
Sw Off, On
Low Gain -12–12 dB
Low Freq 20–2000 Hz
Low Q 0.3–10.0
Low Type Shlv, Peak
Mid Gain -12–12 dB
Mid Freq 200–8000 Hz
Mid Q 0.3–10.0
High Gain -12–12 dB
High Freq 1.4–20.0 kHz
High Q 0.3–10.0
Hi Type Shlv, Peak
Level 0–100
VS8F-2 Algorithm List
98
Stereo Multi
This algorithm connects a stereo noise suppressor, stereo compressor/limiter, stereo
enhancer, and a stereo equalizer in series.
fig.ap(efx)-41(stm_blk.eps)
Input L
Input R
Output L
Output R
Noise
Suppressor
Noise
Suppressor
Equalizer
Equalizer
Enhancer
Enhancer
Compressor/
Limiter
Compressor/
Limiter
