*1 Valid when Equalizer Select is “3 Band EQ.”
*2 Valid when Effect Switch is except “Off.”
*3 Valid when AUX Switch is except “Off.”
*4 Valid when Effect Insert Switch is except “Off.”
Marterblock
* If two VS8F-2 (s) are installed in your VS-1680, the “AUX1” will change to the “EFX1,” the “AUX2” will change to the
“EFX2,” the “AUX3” will change to the “AUX.”
Parameter name Display Value Initial value
Master Level MASTER 0–127 current Master Fader setting
Master Balance MASTER L63–0–R63 0
Monitor Level MONITOR 0–127 current MONITOR knob setting
Monitor Balance MONITOR L63–0–R63 0
AUX A AUX.A EFX1, EFX2, AUX1, AUX2, AUX1 (*1), AUX (*2)
AUX3
AUX B AUX.B EFX1, EFX2, AUX1, AUX2, EFX1
AUX3
Monitor MON MST, EFX1, EFX2,AUX1, MST
AUX2, AUX3, REC, ST IN
Digital Out 1 DOUT1 MST, MON, EFX1, EFX2, MST
AUX1, AUX2, AUX3
Digital Out 2 DOUT2 MST, MON, EFX1, EFX2, MST
AUX1, AUX2, AUX3
Effect Insert Switch(1–4) EFXIns (1–4) Off, Ins Off
Effect Insert Send Level (1–4) Snd -42–6 dB 0 dB (*3)
Effect Insert Return Level (1–4) Rtn -42–6 dB 0 dB (*3)
Direct Out DIR OUT Off, 1–8, 9–16 Off
Effect Send Level - 0–127 100
Effect Send Balance - L63–0–R63 0
AUX Send Level - 0–127 100
AUX Send Balance - L63–0–R63 0
*1 Valid when any VS8F-2 is not installed, or only one VS8F-2 is installed.
*2 Valid when two VS8F-2 effect expansion boards are installed.
*3 Valid when Effect Insert Switch is “Ins.”
Parameter List
