DlyRSS (Delay RSS) (p. 113)
Time 0–1200 ms
Shift L1200–0–R1200 ms
C.Time 0–1200 ms
RSSLvl 0–100
C-Lvl 0–100
LF Damp Gain -36–0 dB
LF Damp Freq 50–4000 Hz
HF Damp Gain -36–0 dB
HF Damp Freq 1.0–20.0 kHz
FBLvl -100–100
EfxLvl -100–100
DirLvl -100–100
VS8F-2 Algorithm List
86
Delay RSS
This algorithm is a delay with three independent delay sounds. RSS is connected to each
output, left and right, and the sound of the left channel is placed 90 degrees left, and the
sound of the right channel is placed 90 degrees right. Feedback can be applied to the out-
put of the center delay.
fig.ap(efx)-15(dlyrss_blk.eps)
Output L
Output R
3 Tap Delay
Feedback
R ch Delay
L ch Delay
Center Delay
Direct Level
Direct Level
Input L
Input R
RSS
RSS
Chorus RSS
This algorithm is a chorus with RSS connected to the output. The sound of the left channel
is placed 90 degrees left, and the sound of the right channel is placed 90 degrees right.
fig.ap(efx)-17(chorss_blk.eps)
Input L
Input R
Chorus
Output L
Output R
Direct Level
Direct Level
RSS
RSS
ChoRSS (Chorus RSS) (p. 113)
Rate 0.1–10.0 Hz
Depth 0–100
EfxLvl -100–100
DirLvl -100–100
